Carbon interior


  • Please log in to reply
11 replies to this topic

#1 suparman

suparman

    Junior Member

  • Members
  • PipPipPipPip
  • 149 posts
  • LocationGrand Junction co

Posted 12 July 2011 - 10:27 PM

So I want to make new interior panels out of carbon fiber, maybe delete some bulges and streamline some areas on my '73. Could I Just put release agent on the inside of the existing panels and vacuum bag it or maybe make a mold of the parts using plaster. I really don't know I have been reading and watching movies about vacuum bagging for two days now and am trying to move forward with my idea. Maybe I should just move to a big city so I can find local people to talk to in person lol. Any insight would be awesome. Thanks.

Edited by suparman, 12 July 2011 - 10:28 PM.

If you put the federal government in charge of the Sahara desert in five years there’d be a shortage of sand. -Milton Friedman

#2 narcolepZy

narcolepZy

    Newbie

  • Members
  • Pip
  • 3 posts
  • LocationMO and FL

Posted 12 July 2011 - 10:34 PM

If you find a way to do it and it looks good with good quality or find someone that can do it for cheap but not sacrificing quality let me know I SHOULD be getting an ZX in next couple of days n would love some CF in it.

#3 KyleG

KyleG

    Junior Member

  • Members
  • PipPip
  • 35 posts
  • LocationOshawa Ontario Canada

Posted 13 July 2011 - 04:04 AM

Skinning the part in CF might be more useful to you than molding the part. Here's a link to a youtube vid on how to do it.



You could use body filler to modify the parts, then lay CF over them when you've got them the way you want. If you decide to make a mold, these guys also have vids on how to do that with out vacuum bagging. If you do end up doing it, post up pics of the results! That would be cool to see.

Good luck!

#4 bens1088

bens1088

    Member

  • Members
  • PipPipPipPip
  • 215 posts
  • LocationBay Area / Santa Barbara

Posted 13 July 2011 - 02:41 PM

Or carbon fiber vinyl. Much cheaper and easier.


www.dapperlighting.com Headlight upgrades for all 240z-280zx's




#5 suparman

suparman

    Junior Member

  • Members
  • PipPipPipPip
  • 149 posts
  • LocationGrand Junction co

Posted 14 July 2011 - 12:01 PM

Yea I did the carbon fiber vinyl look alike on a couple parts not digging it. The panels I have are kinda brittle and I really like the look of a stripped out interior on the z. So concept is to make a bunch of molds that closely match the interior sheet metal. Fiberglass would work to, I don't care about having the carbon look so glass would be cheaper. I am hoping to order the resin infusion kit from http://www.carbonmod...tarter-kit.aspx in a couple of weeks I am just not sure the best way to make the molds they also sell a mold kit kinda looks like chopped glass and clay it will make multiple copies of the part. I only want one copie so I am thinking plaster would be cheaper and easier to get a hold of I just don't know if the gel coat ad-hears to plaster Hell if I cant figure it out I may just sheet the car with aluminum and pop rivets, that will streamline it. this link is to their mold making video.
If you put the federal government in charge of the Sahara desert in five years there’d be a shortage of sand. -Milton Friedman

#6 suparman

suparman

    Junior Member

  • Members
  • PipPipPipPip
  • 149 posts
  • LocationGrand Junction co

Posted 14 July 2011 - 01:43 PM

What about a silicon mold?
If you put the federal government in charge of the Sahara desert in five years there’d be a shortage of sand. -Milton Friedman

#7 Jody

Jody

    Newbie

  • Members
  • Pip
  • 1 posts
  • LocationTyler, Texas

Posted 11 August 2011 - 07:45 PM

Don't wrap. Do it right if you're going to do it.

#8 suparman

suparman

    Junior Member

  • Members
  • PipPipPipPip
  • 149 posts
  • LocationGrand Junction co

Posted 11 August 2011 - 11:13 PM

Yea..I don't like the wrap idea...But I am not getting or finding the answers I need on mold making materials. I don't want to do a glass lay up I was hoping fro something like plaster where I could Just pour it and get a one and done mold out of it no luck figuring that out yet so maybe this is just another failed idea.
If you put the federal government in charge of the Sahara desert in five years there’d be a shortage of sand. -Milton Friedman

#9 ZmattZ

ZmattZ

    Moving Up

  • Members
  • PipPip
  • 30 posts
  • LocationSan Diego

Posted 14 August 2011 - 09:16 PM

Yea..I don't like the wrap idea...But I am not getting or finding the answers I need on mold making materials. I don't want to do a glass lay up I was hoping fro something like plaster where I could Just pour it and get a one and done mold out of it no luck figuring that out yet so maybe this is just another failed idea.

from what ive heard its the laying of the actual carbon fibers which is hard, even harder to get it aesthetically correct. I know a majority of the CF s2000 hardtops were just carbon wrapped on the outside. I will be trying out wrapping pieces once i start to makeover my interior.
Posted ImagePosted Image
1jz turbo. MOMO. centerline. ground control. personal. HKS. nardi. mugen. dapper lighting. worksbell. NRG. Arizona Zcar. KOSO.

mattheinzphotography


#10 Wedge

Wedge

    Member

  • Members
  • PipPipPipPipPip
  • 505 posts
  • LocationAlma, Québec, Canada

Posted 22 August 2011 - 01:29 PM

I have had a good forum thread form a french civic forum about CF and molding ill post the adresse maybe Google translattion could work ?

Original=French original
Translation=My linkgoogle translation
Its very informative i did a pair of motorcycle mirrors following this guide and you can even add vaccum bagging if you want

Edited by Wedge, 22 August 2011 - 01:34 PM.

Their will always be somebody faster then you!
1978 silver 280Z. RB26 in progress.

#11 Wedge

Wedge

    Member

  • Members
  • PipPipPipPipPip
  • 505 posts
  • LocationAlma, Québec, Canada

Posted 22 August 2011 - 01:38 PM

This link is usefull to just Google search you will find Tons of info !
Carbon fiber 101

Edited by Wedge, 22 August 2011 - 01:40 PM.

Their will always be somebody faster then you!
1978 silver 280Z. RB26 in progress.

#12 Rayven14

Rayven14

    Member

  • Members
  • PipPipPipPip
  • 170 posts
  • LocationCalifornia

Posted 19 September 2011 - 10:52 AM

Plaster is a NO GO! Its very pourous so when the resin dries it actually is impregnated into the plaster and there is no way your getting that apart.

IMO your gonna have to make a fiberglass mold with a gel coat finish. If properly prepared your mold should have a mirror like finish making it non pourous and your parts should literally fly outta the mold with little effort. However, if mold making were easy... all of us would be doing it. Honestly, its something you gotta love!
