christianmoller

got mine yesterday and they look great except for the mounting kit for the smaller ones, they are 2 millimeters small in the outer circumference or it could be my old dash maybe. And i need to ad some anti glare to the meters...

Good evening, I now have a working two speed PWM controlled C7 fan. I used an Arduino to create a PWM signal at 50 percent(LOW) 90 percent (HIGH) and some slope up/down between the different stages. I added a voltage regulator i had around when fixing my dodgy gauges on the Datsun (LM7810). /Christian

Good evening gents:), As my ECU doesn't seems to handle PWM controlled fans i got introduced to a new world, Arduino uno. I only have High/low in my ECU so to run my expensive Corvette C7 fan i have to buy an Arduino uno to solve this problem. This is a completely new world for me so this would be a side project to get it to run on high and low. Thanks Christian

Hello to you all ; I have forgotten how small and tiny my car is after taking it down from the stands After i had the engine run in the car i started chasing trouble codes, two on the throttle pedal one on crank relearn and one on clutch position sensor. The throttle pedal shows two codes, one high and one Low, clutch sensor and one crank relearn. "P0122 - Throttle/Pedal Position Sensor A Circuit Low (Permanent) P0223 - Throttle/Pedal Position Sensor/Switch B Circuit High (Permanent) P0315 - Crankshaft Position System Variation Not Learned (Permanent) P0807 - Clutch Position Sensor Circuit Low (Permanent)" About the crank relearn, i'll wait with that until i can drive the car i think. Clutch sensor, is it wise to have one? I have no problems making a braket for one and wire it in. The throttle pedal is the one supplied with the GMPP harness and ECU and it looks like it is a Cadillac unit, and is wired as a Cadillac but i'm using a Camaro ZL1 ECU, could that be a problem? I have used schematics from a 2012 Cadillac and it seems to work except for the FPCM. I have tried to get "Alldata" and the "acdelco" schematics but no luck as i have no company/business. Have a nice evening Christian

Finally, its alive😀. After a lot of crimping battery cables and a lot of other things i started it up today. I have some problems with the FPCM communication and a code on the throttle pedal but i 'll look in to that tomorrow. You tube video on start up. Cheers Christian

Slow progress.........again. I have mounted the harness and also the FPCM in the rear behind the driver seat. Battery tray has also been mounted behind the passenger seat. CANbus and ignition(12v) wire has been routed to the rear as well. /Christian

Hello, It does fit, i have 5/8(16mm) to the hood. My crank is at the same location(height) as the L26. My engine mounts are homemade so i had the ability to adjust for the AC compressor. Have a nice evening Christian

Hello 🙂! Engine is back in the car again and some minor work has been done but not much...... Time to mount the FPCM and battery in the rear and harness of course. /Christian

an update 😄 Life comes in between, other things has to be done but... Fueltank has been moved backwards 1" to make more room for the fuelpumps and filter. a new fuel line is made only thing left for the fuel is the flex fuel sensor. Pick up tube in tank has also been made. Front cross member has been reinforced. I have also pressure tested the AC lines and it looks good so far (N2 10 bar). A new flywheel is made so it's now time to measure clutch slave height.

Thanks! There will be an update soon........ It has been some changes at work so there has been other things to think of so not much happens in the garage. /C

Those mirrors looks very nice, very close to the 1974 oem that i have on driver side. /C

Hello,🍺 I finally had the engine painted, feels good. Not the correct Datsun blue but it will work. Heads went silver and the starter, alternator and AC compressor will be black wrinkle finish, engine brackets are semi gloss black. I also fitted a oil cooler and of course some more brackets😂. And a not so good pic of the man behind the spray gun 🤔 Have a nice evening

Hello, I got a bit crazy over all boxes,metal parts, packing material, bubbel wrap and so on that have build up over some time after this winters building so i cleaned up the garage of garbage so a trip to the city dump is planned for tomorrow.

Thanks Berton, I have tried to locate the part in the red circle, what is it called, cover, lid ,base?!?. What is the height of this part? Cadillac don't exist here in Sweden so to find one i must look in US.

Hello, Picture is all black for me. I'm also interested of what the linkage looks like as i thinking of going that route instead of the F-body way. /C
