Ledphoot Posted December 15, 2006 Share Posted December 15, 2006 For many years doing customizing I would trace a photo of whatever I was building, blow it up on a copier and make a bunch of prints. Then I would sit down and use colored pencils and stuff to work out paint schemes and body mods. Damn shame I threw them out when i was done.. I even use to photo engines standing in front of the bay and cut one motor out and lay it on the other photo. Since your usually right at the bumper, you can use the scale of the pic to test engine fit. I used to have a 500 caddy in a Pinto wagon when everyone said it couldnt be done in a stock bay. I did it. Moved center firewall back 9" but I did it ! Quote Link to comment Share on other sites More sharing options...
veritech-z Posted February 16, 2007 Share Posted February 16, 2007 I saw this new Spoon widebody S2K, and thought it reminded me of one of the concept sketches I'd done a while ago. I wonder if this kit could be adapted to work on a Z? I've never seen one side by side to get a good idea of the proportions. Quote Link to comment Share on other sites More sharing options...
OlderThanMe Posted February 17, 2007 Author Share Posted February 17, 2007 Ever since we started doing these sketches of Zs with open front fenders I have seen several cars running around with open front fenders like on that S2K...grrr... Quote Link to comment Share on other sites More sharing options...
veritech-z Posted February 17, 2007 Share Posted February 17, 2007 I've seen Camo blowing up big time as well...I can't prove it, but I suspect that these threads are getting around... Quote Link to comment Share on other sites More sharing options...
OlderThanMe Posted March 20, 2007 Author Share Posted March 20, 2007 yummy...another sketch. Drew it to get some relief right after midterms... Quote Link to comment Share on other sites More sharing options...
veritech-z Posted March 21, 2007 Share Posted March 21, 2007 Scoop-a-licious! OTM, do one of the side of that kit for me, I'm curious what's going on with the fender there behind the wheel... Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 6, 2007 Share Posted April 6, 2007 Forced Perspective, Attack! Kind of a concept of what I want to do with my intercooler if I ever get around to slapping all my turbo stuff on to my L before I get around to getting serious about an SBC. It would be ducted from underneath via the front, and the louver plate should help create some low pressure above the hood and do some extraction. Quote Link to comment Share on other sites More sharing options...
Guest Arvin Posted April 7, 2007 Share Posted April 7, 2007 Awesome work, fellas! And keep drawing - its like working out at the gym. Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 8, 2007 Share Posted April 8, 2007 veritech, theres a video floating around of a fairlady with hood louvers like in your drawing. I want some! You've probably seen this before but I heart those louvers... http://video.google.com/videoplay?docid=-6465617191604514213&q=240z+turbo&hl=en Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 8, 2007 Share Posted April 8, 2007 Really? A riveted on louver panel like that? I've seen people actually louver a 240 non-vented hood all over, but I hadn't seen anyone do a seperate panel...It was a solution I came on when I was trying to figure out how I could get both a Carbon Fiber hood AND the louvered hood I always wanted...cut a big rectangle out and then rivet on some aluminum louver panels. I'd be curious to see how it actually looks on a real car... Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 8, 2007 Share Posted April 8, 2007 I edited my previous post with a link to the vid I was talking about. That car looks to have blended louvers, but I like your idea for riveted on ones. Quote Link to comment Share on other sites More sharing options...
OlderThanMe Posted April 10, 2007 Author Share Posted April 10, 2007 Very cool sketch Max! It looks like this summer I'll be doing the bodywork and raising compression to 10.2:1 before I retire the L26 to go to another project... It looks like I'll be doing the body in the "boodlefoof style"... I'll have some more sketches soon. Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 11, 2007 Share Posted April 11, 2007 Yeah, I was thinking of giving my L28 a last hurrah by slapping my T4 on it, but that plan was dependant on finding a turbo manifold for like $50 or less (anything more than that is just cutting into my V-8 plans...) which hasn't happened yet. Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 11, 2007 Share Posted April 11, 2007 veritech, do you have a source for those "bolt on" louvers? I'm seriously thinking about doing that with my car. Hope you dont mind me stealing your idea. I need to get some fuel injection up and running then I can start worrying about the turbo stuff. but the louvers will help keep underhood temps down, so I'll go ahead and do that. JC Whitney has them in ABS, anyone have sheet metal ones? Or should I just talk to one of those guys that do it for $1 a piece and get them to make me a strip? Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 11, 2007 Share Posted April 11, 2007 I found a bunch of Louvers on ebay in different deminsions. I wasn't sure if I would do a strip like that, or do a sqaure in front of the power bulge. http://cgi.ebay.com/ebaymotors/Mack-CH-CL-Stainless-Hood-Louver-Set-NIB-No-Res_W0QQcmdZViewItemQQcategoryZ6755QQihZ004QQitemZ140104351211QQrdZ1 http://stores.ebay.com/928-Motorsports_Louvers_W0QQcolZ2QQdirZQ2d1QQfsubZ8QQftidZ2QQsclZ0QQtZkm Seems like there used to be a better selection, but this was all I could come up with right now. You may come out better having them made if they can do it at $1 a louver, plus you could just make them to your own specs that way instead of trying to make them fit. Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 12, 2007 Share Posted April 12, 2007 I may get them made to my specs anyways. I think if they were angled to follow the peak in the bulge it would look better. Hmm, I'll have to do some thinking, style, size, attachment method, finish, etc... Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 12, 2007 Share Posted April 12, 2007 I was thinking that if they had an angle to the front, like the 280z vents, but long, then that would look pretty nice. Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 12, 2007 Share Posted April 12, 2007 I'm curious where you were planning to run the rear pipe for the intercooler? back up to the front or sneak it behind the engine? I think I like the natural metal look but then I would have to use screws or similar to hold it on so it would be easier when I repaint the car. hmm, so many decisions for one little detail. Quote Link to comment Share on other sites More sharing options...
veritech-z Posted April 12, 2007 Share Posted April 12, 2007 does this help? That's the plan for now, anyway. I won't know if it's workable until I actually get in there to do something with it... Quote Link to comment Share on other sites More sharing options...
Chewievette Posted April 12, 2007 Share Posted April 12, 2007 That certainly helps! I hadnt thought about keeping the front mount IC but I dont see why not. As long as you dont mind me stealing your basic idea, I'm going to start playing around with setups on my car, since its still not back together yet. Quote Link to comment Share on other sites More sharing options...
