  1. gmorrone1214

    Building MS2 V3 Board

    Yes sir I have.
  2. gmorrone1214

    Building MS2 V3 Board

    I acutally changed it using the proto area after posting that picture. So now the resistors sit in there with leads to the appropriate holes. Jumpers are as followed: VR Sensor: -VRIN to Tachselect -TSEL to VROUT Single High Output Coil -IGBTOUT to IGN -330r 1/4w res IGBTin and top of R26 Power -S12c to JS9(+12c)
  3. gmorrone1214

    Building MS2 V3 Board

    About to start up the car this weekend, just have to finishing wiring the distributor and the fuel pump and then its good to go. May be a dumb question but wiring the distributor as per this diagram ----The 12v+(B/W): Guessing this is switched? I am using the relay board, so is there any slots I can plug it into or just find a random 12v switch wire?
  4. gmorrone1214

    S13 Throttle Body TPS issue

    How would I wire this to Megasquirt? The middle pin should be the signal wire, but how do I know which pin is the ground and the other power?
  5. gmorrone1214


    Just ran into a clearance problem that I do not see addressed in other forums. The way the steering is set up (outlined in red) there is no way that I can fit this hy35 holset in there. Is the swap that I need manual rack and pinion to make this fit? Did not think this was going to be a problem with the swap ugh 😤
  6. gmorrone1214

    Found a new shell - would you consider this clean?

    Test it with a screwdriver (poke around at it) and see if it is completely rusted out structurally. If you can mig weld , or weld in general it isn't a hard fix. And if you dont want to patch fix it they also have complete floor boards and rails you can weld on.
  7. gmorrone1214

    Building MS2 V3 Board

    Roger that. About to wire it up in the ZX and have chickenman help with the tune.
  8. gmorrone1214


    Delete please, got the part.
  9. gmorrone1214

    Building MS2 V3 Board

    Just as an update I got the board firmware downloaded and hooked up to Tuner Studio. When using the megastim and moving the adjusters the corresponding gauges in the studio move, all besides the RPM (Well starts to then stops , says it needs to be calibrated). However none of my LED's on the Board or the megastim light up, is this normal? Also the board now has the motherboard along with R43 for High output coil.
  10. gmorrone1214

    Building MS2 V3 Board

    Set up for single high output coil 82 turbo dizzy no PWM idle
  11. gmorrone1214

    Holset HY35 Exhaust Flange Adapter?

    Did you ever get the HY35 exhaust flange welded up and downpipe made? Currently looking to install the same setup in my vehicle.
  12. gmorrone1214

    Building MS2 V3 Board

    Powered it with the battery and all is well. Checked the voltage according to the hardware manual and everything checks out. All that is left is installing the transistor for the single coil setup. Once I have the modifications done to the jumper wires I will upload a picture just to make sure that it is correct.
  13. gmorrone1214

    Building MS2 V3 Board

    I was trying to do that step however I am not getting any power to PCB at all. With the 9v in the stim, I am not even getting a reading at the + terminal of the stim when it is connected to MS2 board. Ill just bench test it with a 12v battery and the 1amp fuse to the 28pin to see if the stim is the problem.
  14. gmorrone1214

    Building MS2 V3 Board

    Okay ill make sure to do that once I get the resistor. So I went to test the board and I plug the stim in with a 9v and noting happens. I am not even getting any power readings at the stim. Isn't the stim not powered until connected to the board? If so even when connected I still do not have any power being drawn. I saw the stim manual on how to use it and it says I have to plug the other port into the computer and upload the firmware and studio, shouldn't I be able to just check for voltage without doing all of that? Only reason I ask is because my PC does not have a CD port on it, waiting for my laptop to arrive.
  15. gmorrone1214

    Building MS2 V3 Board

    So my kit came with the BIP373 (Q16), it also came with BIP373 330o 1/4w, so i wont have to purchase the kit. Do I use the BIP373 330 1/4w at all? Instead of on the + wire from the VR sensor which leads to (DB37 pin24), where on the board would I solder the resistor? For what its worth thanks for your help, along with chickenman and everyone else.
