jhm

Brett- Are you familiar with Spectre Performance's website? They have a decent amount of engineering and technical data on each of their products (ducting, air plenums, filters, etc). Check out their tech forums and application guide for airflow data. The data on their 4" ducting should help answer your question (even if you use a product other than Spectre's). Hope this helps. John

Caleb- I had some minor body and paint work done on my 4Runner a couple years ago. After talking to a few shops, I decided to go with "Tim's Custom Painting and Collision Repair". The results were great....they did awesome work, and they finished the work in only a couple days. The price was maybe a little higher than market average, but certainly not unreasonable and well worth it considering the quality of their work. Tim's is at: 280 Production Drive (off of Rt 17, just south of Victory Blvd) Tabb VA 757-595-5058 Stan's was one of the shops I talked to before going to Tim's. The guys there certainly seemed knowledgeable, but I don't have any firsthand experience with them. Good luck and keep us posted. Good info for future reference! John

Just a thought....when you disassembled the parking brake, did you loosen the main adjusting linkage under the car (inside the driveshaft tunnel?) If so, it probably just needs to be retightened to its original position. It's a U-shaped yoke that connects the single linkage from your e-brake handle to the two linkages going to your drum brakes. Hope this helps.

rskdsk- If you still suspect that the problem lies in the ignition switch, check out my thread on testing the switch. http://forums.hybridz.org/showthread.php?t=153191 Good luck with it....hope you sort it out soon! jhm

darkzebra- If you're still looking for a good low-profile fan, check out Spal. Their stuff is quality-made, and they've got a pretty good rep. I've been running one of their 16" low-pro fans for the couple years without any problems. http://www.spalusa.com/store/main.aspx?p=CategoryBody&c=FALO

To test the switch, remove it from the combination switch mounted on your steering column. (I suppose you could actually test the switch without removing it, but that would require some really painful contorted time under the driver's side dash!) Start by removing the plastic cover on the steering column. After it's off, remove the 4 phillips head screws that secure the combo switch to the steering column. After that, you'll have the two sides of the combo switch hanging down off your naked steering column. Unplug the 6-position electrical plug from the ignition switch. Remove the two little screws holding the switch's electrical portion to the keyed portion of the switch. The electrical portion is a small silver barrel with 5 prongs on one side, and a rectangular slot on the other. You can now test your switch. Using the schematic in my Sep 15th post, test continuity of your switch in each of the 4 positions: Off, Acc, On, Start. You'll probably need an assistant to test the switch in the 'Start' position (due to the fact that the switch is spring-loaded in 'Start') -- one person can hold the switch in the 'Start' position while the other person tests the leads on the back of the switch for connectivity. If the continuity in your switch does not match the schematic, then your switch probably needs to be replaced. My switch turned out to be bad because I had no connectivity between the ignition ("IG") and the battery ("B") in the 'Start' position -- meaning that I had no juice going to the ignition while the starter was cranking the engine. Weird, huh? Like I said in my earlier post....it's an cheap and easy fix to replace the switch (electrical portion only). $16 from Z Car Source. New switches are available from other sources, but keep in mind that many of them may try to sell you a complete switch (electrical plus keyed portion) for more money. Good luck and happy motoring!

Check out the ZHOME webpage -- it's a great source of historical and tech data. http://www2.zhome.com:81/

It's called a power shunt. When it's wired correctly, it has 2 two-prong plugs going into it. One of the plugs is wired with thick 12-gauge wire, and the other is wired with much thinner (maybe 18 gauge?) wire. Given that it's probably carrying 60-90 amps, I would remove it or ensure that it's wired correctly. You can find MANY threads on this subject in the "Ignition and Electrical" sub-forum. The unit's primary purpose (if not the only purpose) is to bleed off enough current from the car's main power leads (the thick wires) to operate the ammeter in your dash. Neither the gauge nor your dash harness are designed to handle the full load of the main power leads. Later cars came with voltmeters (vs ammeters) and did not have the power shunt, if I recall correctly. Guys wishing to convert their ammeter setup to a voltmeter setup are able to remove the power shunt. r/jhm

datsfast- "Boring" nothing...that's a nice, clean, factory-looking installation!!

Hey all- Had some free time on my hands so I decided to fab up a simple heat shield for my master cylinder and master-vac (also protects the brake warning switch). Used thin-gauge galvanized sheet steel from Lowes, coated with a layer of Thermo-Tec 2000 deg heat shield. Cheap, easy, and relatively effective. r/jhm

What year and model is the car?

Yeah....good idea to call them. They often have lots of stuff that doesn't appear on their website. Good luck!

Thrustnut- Have you tried Z Specialties yet? http://www.datsunstore.com/index.php/cPath/37_267 Great folks to deal with, and I've always had good luck with them for these little stock and repro parts. Good luck and happy motoring. jhm

Hoov- Did you say "rectal scanner" or "retina scanner"???

Barfife- I'm digging your ragtop Z! I think the S30's have such natural lines that they make great convertibles. Nice ride! Here's my '75 that I converted a few years ago when I was living in SoCal, then brought her with me when I moved to CO. Used a Fiat convertible frame with a custom black canvas top for the conversion. My daily driver for 3 years until I traded her for a Euro-spec Porsche 928S. jhm

Guys- Check out: http://www.atlanticz.ca/zclub/techtips/electrical.htm or: http://www.xenons30.com/reference.html Should contain everything you need (and more!) r/jhm

570- Check out this thread...may have the info you're looking for. http://forums.hybridz.org/showthread.php?t=144958&highlight=vote+scarab+air+filter jhm

Nothing special....standard automotive bulb. Here's another shot (from below, looking straight up at the light).

This is a great idea, especially for folks with shaved rear ends! Nobody wants that ’68 Chevy pickup behind you plowing into your rear end because he didn’t see your brake lights. I put a similar system on my car as Cygnus’, but used these LED lights from Harbor Freight vs the PC lights he used. Got the lights at my local store on sale for $7.99 each: http://www.harborfreight.com/cpi/ctaf/displayitem.taf?Itemnumber=98408 They definitely make the car more visible when braking, and add a little bling at the same time. Enjoy, and happy motoring. Drax- If you use the PC lights, I wouldn’t recommend bending them double…..but it would be easy to mount two strips side-by-side to create a double row (same goes for the Harbor Freight lights I used). John

All- Here’s a great alternative for your interior dome lamp. They’re available from most RV parts suppliers, but I got mine from CarParts.com for $13: http://www.carparts.com/autoparts/Product/Pr-p_Product.CATENTRY_ID:2003343/c-10618/Nty-1/p-2003343/Ntx-mode+matchallpartial/N-10618/tf-Browse/s-10401/Ntk-AllTextSearchGroup?Ntt=aircraft+style+interior+light They come in multiple styles, are available in black or silver brushed aluminum, and the light fixture swivels 360 deg. So if your dome lamp has crapped out, or just gone plain missing over the years (like mine had), and you don’t want to fork out the cash for an original-style replacement unit; you may want consider this nifty alternative. jhm

Glad you got it working, Dave. Next week I'll be putting in a putting in a third brake light like you did -- that was a great idea (and cheap...I always like cheap!)

Well, after owning the car a year, I finally decided to get my clock working (since I was already into the dash chasing dash harness electrical gremlins). From what I've read, these old clocks on the S30's are amazingly robust -- even after 35 years of hard use. They often freeze up if the car has sat for a long time with a dead battery or the battery disconnected. Most can be coaxed into life again, with a little cleaning up and lubricant. Use a small amount of very light-weight oil on the gears and spinning mechanism. Ensure all parts are able to move freely. And, as I found out, there are two screw pins that provide the mounting platform for the spring/counterweight mechanism (which is basically the motor for the clock). These two screw pins may need to be adjusted to get your clock working....they need to be just tight enough to hold the spring/counterweight mechanism securely, but not so tight that they impede free movement of the mechanism. Now my clock is working again and keeping perfect time. It's amazing how much the little things in life mean! jhm

Jake- I'm guessing that your grounds are all good since you hotwired the lights and they worked for you. If not, bad grounds are always a problem with the lights....fortunately bad grounds are easily fixed. WRT the turn signals, could be your flasher's crapped out. It's under the dash on driver's side, just to the left of your left knee. There's two there...one for the hazards and one for the turn signals. I just replaced mine -- $2.99 for a new one from Pep Boys. Headlights could be the combo switch maybe? Have you removed your steering column cover and checked the switch leads and connections? Good luck and be sure to post your results! jhm P.S. I've been watching your build thread for a while now....car looks like it's coming together really nicely. Great job with the engine swap!

Slo Mo- Go for it! I've got a 350 from a '78 C-10 in my 260....runs great and reliable as a brick. Yeah, the stock HP ain't awesome, but it's pretty darn torquey. I've spruced mine up with headers, Edelbrock Performer intake, Holley 600, and Moroso super HEI. May eventually add a cam, but it runs great for now. Good luck and be sure to post your results. jhm

RM- I'll take it!! Already sent you PM. Thx. jhm
