DuffyMahoney Posted February 20, 2020 Author Share Posted February 20, 2020 My oer/ SK intake plan is going to be perfect. Basically I’m looking for a clean way to do iac and pcv. I will have a plate machined to cap this faux balance bar. Then tap each runner for 1/4 or 3/8. I love the oer/ Sk linkage. The IAC and PCV will be done on the bottom out of sight. This is what the Sk/ oer intake look like under that cap. Casting is a little rough for my personal tastes. I will use a Bosch 0280140551 IAC. Quote Link to comment Share on other sites More sharing options...
tioga Posted February 20, 2020 Share Posted February 20, 2020 Looks good. I have looked at the FET intake for the same reason. I have thought I might get the jenvey 50’s with intake and see what that looks like. On a side note I recently added a stock intake heat shield to my customer car with the harada intake. It fit really well and makes a huge difference on intake heat. The under carb/throttle body heat shields really fall short of the area with the most heat. Since the car was already together I just made a crude bracket to hold it from the top but it still looks ok. For my mangoletsi intake since it is webbed it should be able to be done cleaner. I have also thought with the Jenvey since it is angled up a bit it would fit even easier. You could also well bolt bosses to the bottom. Quote Link to comment Share on other sites More sharing options...
tioga Posted February 20, 2020 Share Posted February 20, 2020 The bolt is in a stock location hole on the heat shield. Does not rattle. Quote Link to comment Share on other sites More sharing options...
tioga Posted February 20, 2020 Share Posted February 20, 2020 It also does not interfere with the Oer under throttle heat shield and gives a double layer for a bit. Might think about this while messing with the underside. I have a couple very nice condition heat shield I was thinking I would send out for a heat reflective coating. Quote Link to comment Share on other sites More sharing options...
tioga Posted February 20, 2020 Share Posted February 20, 2020 You should get the top aluminum plate engraved with the old SK sport kit graphic. Today with the laser engravers prob wouldn’t cost much. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 21, 2020 Author Share Posted February 21, 2020 21 hours ago, tioga said: You should get the top aluminum plate engraved with the old SK sport kit graphic. Today with the laser engravers prob wouldn’t cost much. I will make the cap nice looking. Somesort of SK logo. I will keep it simple, but add some flare. The casting is pretty rough, first step is to knock that down. My local engine shop has a huge vibratory polisher. I might try that first. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 22, 2020 Author Share Posted February 22, 2020 (edited) Datsun Spirit valves are in my E31! Next is flow testing. Thanks for all the help Andrew Kazanis Details: New guides, bronze guide liners, reamed to size, seats cut, three broken studs removed. Edited February 22, 2020 by DuffyMahoney Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 23, 2020 Author Share Posted February 23, 2020 Numbers are in. She flows well! Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 23, 2020 Author Share Posted February 23, 2020 (edited) Duffys E31 Flow Testing 63" Static 15" Static 63 Degree Shop 45 Intake Valves 36.5 Exhaust Valves DSI Big Valves LIFT Manometer CFM LIFT Manometer CFM Porting By Andrew Kazanis of Mad Greek 0.05 50 35 0.05 14 35 Date: 2/22/2020 0.1 45.25 60 0.1 13 55 0.15 41.75 90 0.15 12.1 80 0.2 36.5 125 0.2 11.5 95 0.25 33 140 0.25 11 115 0.3 31 160 0.3 10.7 125 0.35 27 190 0.35 10.5 130 0.4 23 220 0.4 10.3 135 0.45 21.5 235 0.45 10.1 145 0.5 21 235 0.5 10.1 145 0.55 21.2 230 0.55 10.1 145 0.6 27 190 0.6 10 150 Datsun Flow Testing Data.xlsx Edited February 23, 2020 by DuffyMahoney Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 24, 2020 Author Share Posted February 24, 2020 Starting cam mock up. I’m using the bonk .535 cam. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 25, 2020 Author Share Posted February 25, 2020 L Diesel Stroker crank. Extra offset ground for toyota rods. I will have full details tomorrow. I had the work done at marine crank. I think it’s 84.5 stroke Quote Link to comment Share on other sites More sharing options...
Derek Posted February 25, 2020 Share Posted February 25, 2020 Looking great Duffy. I'll have my crank back today. I ended up with 84.84mm stroke and setup for the Toyota rods. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 25, 2020 Author Share Posted February 25, 2020 Thanks! I got slightly more. But not a lot. Stroker Diesel crank is back from marine crankshaft! Offset ground to 84.6mm Toyota rod ends 1.8896” Ground main journals to -020” Dynamic balance Ion plasma nitride, straighten and micro polished. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 28, 2020 Author Share Posted February 28, 2020 Iac balance bar is looking good. Next is having it cut. Quote Link to comment Share on other sites More sharing options...
Zetsaz Posted February 28, 2020 Share Posted February 28, 2020 Looks good! What's with all the hybridz pics all over the site uploading in super low resolutions though? Quote Link to comment Share on other sites More sharing options...
calZ Posted February 28, 2020 Share Posted February 28, 2020 2 hours ago, Zetsaz said: Looks good! What's with all the hybridz pics all over the site uploading in super low resolutions though? Everything looks fine for me Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted February 29, 2020 Author Share Posted February 29, 2020 8 hours ago, Zetsaz said: Looks good! What's with all the hybridz pics all over the site uploading in super low resolutions though? I was doing it from my phone? Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted March 5, 2020 Author Share Posted March 5, 2020 Balance bar cap is done. Quote Link to comment Share on other sites More sharing options...
DuffyMahoney Posted March 6, 2020 Author Share Posted March 6, 2020 ITB with IAC and pcv here I come. Which mount looks better. Stock coil mount or the rubber one? Rubber one looks lower profile. Quote Link to comment Share on other sites More sharing options...
Zetsaz Posted March 6, 2020 Share Posted March 6, 2020 What IAC valve are you running? Quote Link to comment Share on other sites More sharing options...
