Questions for those that have put an STI R180 into a 280Z
NewZed replied to garcenw's topic in Drivetrain
Don';t know why a car company would make two parts if they could just flip one and make it work. But, who knows. The bar and diff mount rubber are flexible enough that you can probably pry any combination parts around and get the bolts in. Half shaft angle will affect vibrations though. The automatic 280Z R180 bar is probably stronger and/or stiffer than the 240Z bar, to keep up with the heavier car and bigger engine, Seems like the best route. -
71 240z... need some guidance in my plans.
NewZed replied to RichardPosterior's topic in S30 Series - 240z, 260z, 280z
It's June 2017. Let's see how long this project takes. You need to decide if you want to boil tires or have traction. Mint-tubbing won't be necessary if you just want to make smoke. -
Questions for those that have put an STI R180 into a 280Z
NewZed replied to garcenw's topic in Drivetrain
Just came across this bar for sale - https://maseraticompound.com/products/datsun-240z-rear-transmission-mounting-cross-member -
The bip373 IS the ground wire for the coil. If you test the CAS by pulling it and spinning it by hand you can hear the injectors clicking, because there's no starter motor end engine noise. I've tested a CAS that way by plugging it in to my Pathfinder harness. Turn on the key and spin and you should hear them clicking. It's kind of cool.
-
Do you get injection? Might tell you if Megasqurt is at least using the CAS signal to get half the job done. You can remove the distributor and turn it be hand to listen for injectors clicking. You can also get another CAS, like from a junkyard, and plug it in and spin it by hand to see if you get spark.
-
280z Overheating at low speeds
NewZed replied to sugisan's topic in Trouble Shooting / General Engine
Seems like you're acting on maybes instead of figuring out the cause first. You can leave the hood half-latched to do an air evacuation experiment, before installing grommets or getting a vented hood. And why do they call it a splash shield? And if Chickenman is right about highway speeds how is it going to help your problem? Don't spend on random possibilities if there's still some simple things you can do to get closer to the true cause. -
Sounds like fun. If it hasn't been driven for a long time it might be a stuck valve, or ignition timing. If it's running might as well let it run and loosen up while you check the basics.
-
71 240z... need some guidance in my plans.
NewZed replied to RichardPosterior's topic in S30 Series - 240z, 260z, 280z
You're welcome on the name. I didn't say it wasn't possible. It's just not rational. To followup on rturbo, pick your base engine (looks like you want to go LS) and build up from there. The wrecking yards are sprinkled with cars that had drivers who didn't react faster than the oh shit feeling. Just seems like you're getting ahead of yourself, if you really want to drive what you're building. On the other hand, there are many "builds" happening out there that have never been driven and they've been going on for years. -
I don't know exactly how they work but some 240Z's have an inhibitor switch. I think it's on automatic cars to stop the engine from starting while in gear. If you have an automatic make sure that it's in neutral. Also check for power at the starter solenoid wire when you turn the key to Start. Do that for sure before you replace any parts. I've had a loose solenoid wire that just wasn't making connection to the starter solenoid. Almost bought a new starter... The clicking is probably just the accessory relay turning off power to the accessories, for Starting.
-
You didn't say WHEN you get the clicking noise. I watched parts of the video but can't tell what's happening at the key when the click happens. Is the click when you turn it to Start, or Acc, or Run? I got vertigo before I could tell if you actually turned the key to Start, and had to stop.
-
71 240z... need some guidance in my plans.
NewZed replied to RichardPosterior's topic in S30 Series - 240z, 260z, 280z
"Rabbit hole" seems about right. A fantasy. Why have you chosen such a huge amount of power as your first project? And "on a budget". Apprentice welder. Seriously, what you've proposed is kind of ridiculous. Here's a thread to look through - http://forums.hybridz.org/topic/125328-ford-88-irs-swap-v20/?hl=%2Bford+%2Binch -
Questions for those that have put an STI R180 into a 280Z
NewZed replied to garcenw's topic in Drivetrain
The old edit without ID'ing what's edited... I always add an "edit" in front of my edits. Here's a good site for comparing parts, and sometime the Google will even find old stock for you - http://www.carpartsmanual.com/datsun/Z-1969-1978 If you get the Wolf Creek racing axles, it actually is kind of the inverse of an R200 swap. Except for the pinion shaft flange. http://www.wolfcreekracing.com/index.php?option=com_content&view=article&id=22&Itemid=31 Edit - the reason it's like an inverse R200 if you get the axles is because you can use your stock halfshafts. R180 mustache bar, Nissan pinion flange or modified propeller shaft, and the diff axles, and you're rolling. -
That's a good link and answers a lot of questions. It's an interesting area, the Z car diff mounting is an odd thing.
-
Questions for those that have put an STI R180 into a 280Z
NewZed replied to garcenw's topic in Drivetrain
It does clear things up, by quite a lot. He answered each question, specifically. But you have to put some of your own thought in to it. The first question about mustache bars kind of shows that you haven't even really started thinking yet, or that you don't trust your own thinking. You were on track with the comment about automatic R180's but apparently didn't trust your own thought process. There's a ton out there about R200 swaps. Read up. -
1982 280 ZX Sensor Light, Car Died & Will Not Crank
NewZed replied to CajunZX's topic in S130 Series - 280ZX
Have you tried jumping the starter solenoid wire at the starter? Have a mechanic check your starter. When you turn the key to Start do the dash lights stay on or does everything turn off? Is the "sensor light" the exhaust gas sensor lamp? That's the only "sensor light" I see. Is it a Turbo car with ECCS, or NA with the EFI system? Two different systems. The NA car does not have a brain and the ECCS brain is abbynormal. Neither will shut down the engine, I believe. Too many possibilities, hence the need for more detail. -
1982 280 ZX Sensor Light, Car Died & Will Not Crank
NewZed replied to CajunZX's topic in S130 Series - 280ZX
Need more detail. -
That is right. So, basically, your wiring is not as the factory intended it. Get the factory wiring diagram and make it like it was. Try the Electrical chapter - http://www.nicoclub.com/FSM/280z/1981/
-
Just a refocusing type comment, but driveline balance and runout problems would be more tied to drivehsaft RPM, not load. The original comments about angle changing due to diff nose lifting seem most likely. Based on the stated facts. Something that changes when load is applied. Seems like this latest effort might be helpful but off target.
-
280z Overheating at low speeds
NewZed replied to sugisan's topic in Trouble Shooting / General Engine
Don't forget that if the air in the engine bay is just recirculating through the radiator it won't do much cooling. A lowered car with a front air dam might not allow the hot air to leave. Your observation about what happens with the hood open is a clue. Maybe focus on getting the air out from under the car, or through the hood, or access panels. You might be just spinning your fan blades otherwise. -
You need a diode on one of the wires from the T plug. You didn't say what year car you're working with. But it's a common problem, after people rewire their 240Z's to use an internally regulated alternator. Pretty sure that the L wire is the one that needs a diode. Position the diode so that current only flows to the alternator but not back. Found a good description. I think that all you need to do is add the diode. Post #4. Assuming that somebody else already rewired everything else for an internally regulated alternator. http://www.zcar.com/forum/10-70-83-tech-discussion-forum/110443-more-73-240z-voltage-regulator-swap.html
-
Where's the Google link? It is odd-looking, that's for sure. What kind of Z are you working on?
-
Don't mean to be a downer but if you still have a rubber diff mount in the back, after the PO installed 500 horses, there might be a lot more lacking back there. Kind of sounding like it might be a build budget depletion sale from the PO. Good luck and read some of the SUNNY Z and RebekahsZ threads, among many others, on breaking things and how they fixed them. You might still have the original open diff.
-
Datsun looks like its driving crooked
NewZed replied to JDs78's topic in Brakes, Wheels, Suspension and Chassis
We used to call that dog-tracking. It's caused by the rear wheels being on an axis that is not parallel with the front wheels' axis, when all wheels are parallel to the car body. If you can see something odd about a rear wheel that's a good place to start, Could be worn bushings. How is the wear pattern on the rear wheels? Is this a right hand steering wheel car? Passenger side and right side are the same for US models. I found a few links on the old interweb. These cars don't have a lot of adjustment so you probably have a bent part or worn bushings. https://www.theglobeandmail.com/globe-drive/culture/commuting/dog-tracking-should-give-a-driver-pause/article1367167/ -
280z Overheating at low speeds
NewZed replied to sugisan's topic in Trouble Shooting / General Engine
You have a thicker radiator, an AC condenser, and a shroud of some kind, with electric fans. Anything else up there? Cold air intakes, intercoolers (not clear what engine you're running), horns, alarm systems, spoilers..etc? Maybe you just have too much area blocked and a too long path for the air to flow. A simple test of coolant flow versus air flow might be to increase your idle speed and see if it overheats faster or slower. Since you don't have a mechanical fan all you'll be changing is coolant flow rate. -
It might just be a different style of shaft, instead of a length of machined rod. Could be that the center piece locates and retains the shaft ends in the center of the diff. The sides of the piece also support the spider gear, and act as another bearing surface, probably reducing wear. It looks like just a more robust two pinion diff. Probably little benefit to swapping, unless the other diff is worn. Spend some time measuring wear on the other diff.
